| Image Sensor | 1/2.8” 8MP PS CMOS Image Sensor (0.9071 centimeters) |
|---|---|
| Minimum Illumination | Color: 0.005 Lux@(F1.6, AGC ON), 0 Lux with white light, B/W: 0 Lux with IR |
| Shutter Speed | Auto: 1/3-1/100000Sec |
| Max. Aperture | F1.6 |
| Lens Type | Fixed |
| Lens | 3.6mm (2.8mm and 6mm Optional) |
| Back Light Compensation | BLC/ HLC/ WDR(120dB) |
| Angle of View | 3.6mm: Horizontal 84°, Vertical 48°, Diagonal 97° 2.8mm: Horizontal 96°, Vertical 52°, Diagonal 114° 6mm: Horizontal 53°, Vertical 30°, Diagonal 60° |
| Video Compression | NEXICODE, H.265, H.264 |
| S/N Ratio | 60dB |
| LED Number | IR LED: 2PCS, Warm light LED: 2PCS |
| IR | IR Range of 40 Mtr. |
| Warm Light | Warm Light Range of 30 Mtr. |
| Frame Rate | Main Stream: 8MP (3840 x 2160)@20fps, 4MP (2560 x 1440) @20fps, 1080p (1920 x 1080)@25fps,720p (1280 x 720)@25fps Sub stream: 4MP (2560 x 1440)@20fps, 1080p (1920 x 1080) @20fps, 720p (1280 x 720) @20fps, D1 (720 x 480)@20fps |
| Privacy Mask | 3 Rectangular Zone |
| Day/Night | Color/ B&W (IR-CUT ) |
| Protocol | TCP/IP, IPv4/v6, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, NTP, SMTP, UDP, Qos, ONVIF (Profile S/T) |
| Audio | Built-in Mic |
| Built-in Speaker | Support |
| IR Cut Filter | Support |
| Image Config | Saturation, Brightness, Contrast, Sharpness, Mirror, 3D NR, White Balance, Anti Flicker, Video Tampering |
| Resolution | 8MP (3840 x 2160) |
| Video Output | Network |
| Reset Button | Support |
| Image Rotation | Support |
| Motion Detection | Support |
| ROI | Support |
| Audio Compression | G711A/U, AAC |
| PoE | Support IEEE 802.3af |
| Storage | Micro Sd Card (Supports Max 1 TB) |
| IVS (Perimeter Protection) | Intrusion Detection (based on human and Vehicle Detection), Line Crossing Detection (based on human and Vehicle Detection), Loitering Detection (based on human detection), People Gathering Detection (based on human detection), Motion detection (based on hu |
| Ethernet | RJ-45 (10/100Base-T) |
| Browser | Microsoft Edge, Google Chrome |
| Weatherproof Standard | IP67 |
| Power Source | DC12V,PoE(802.3af) |
| Operating Temperature | -20°C to +60°C |
| Operating Humidity | Less than 95% RH |
| Storage Temperature | -20°C to +60°C |
| Storage Humidity | Less than 95% RH |
| Dimension | 96mm x 91mm |
| Casing | Metal |
| Weight | 430g |
This camera has been designed with the latest and most efficient innovation among the standard video compression designs. Smart encoding algorithms developed by Nexivue help in saving up to 70% more bandwidth than H.265 along with making it more benefi cial for minimizing bandwidth and storage costs. It enhances video coding efficiency while providing high resolution and the rate of frame in the video using Intelligent Region Perception to detect mo tion in each frame.
When the scene is too dark, the image is captured by illuminating an infrared light through the camera onto the scene that greatly helps with making the scene visible for the lens. It delivers color images during the day and automatically switches to the mono chrome feature as the scene darkens.
Regions of Interest (ROI) is a user defined feature that allows the operator to monitor specific areas of a scene while still maintaining overall situational awareness of less important areas.
Nexivue cameras with Power over Ethernet (PoE) technology offer a simple and efficient installation by using a single Ethernet cable to deliver both power and data. This eliminates the need for separate power adapters, reduces cable clutter, and ensures a cleaner setup
